ELEC CITY
Hyundai ELEC CITY running through the city Hyundai ELEC CITY in the city

ELEC CITY

ELEC CITY brings a clean energy experience to your daily urban transportation.

Send Catalog via Email

Send Catalog via Email
Seats
50
/
51
Max Power Output
240
kW
Battery Capacity
290.4
kWh

Highlights

The Future of Public Transportation

ELEC CITY is the beginning of future urban mobility.
It's a new energy experience that will make our cities more pleasant places to live.
It runs up to 420km on a single recharge which takes 68 minutes.
Hyundai ELEC CITY in the city
Rear of Hyundai ELEC CITY

Remarkable Driving Ability
Incomparable Operating Efficiency

Unlike buses powered by internal combustion engine buses, ELEC CITY runs on pure battery power which can reduce fuel costs significantly over the operational life span of the bus. A highly efficient heat pump system can be added as an option to maximize energy and heating efficiency.

Hyundai ELEC CITY being charged
Dad and son riding Hyundai ELEC CITY

Technology

Deliver Solutions, with Your Evolution

Hyundai ELEC CITY stopped at the bus stop Hyundai ELEC CITY stopped at the bus stop
Internal System of Hyundai ELEC CITY
Internal System of Hyundai ELEC CITY
Internal System of Hyundai ELEC CITY
Internal System of Hyundai ELEC CITY
Internal System of Hyundai ELEC CITY
Internal System of Hyundai ELEC CITY
Internal System of Hyundai ELEC CITY

How Electric System Works

Battery
Motor
Battery

Hyundai's lithium-ion polymer batteries have a lower 'memory effect sensitivity that can adversely affect recharing capacity, and they have excellent charge efficiency compared to conventional batteries.

Motor

The ZF main motor and dedicated all-electric drivetrain systems have been optimized for urban routes and operational efficiency.

Fitted with a High-efficiency,
High-quality Lithium Polymer
Battery

The 290 kWh high-capacity battery is appropriate for routes that consume high amounts of electricity with frequent traffic congestion or slopes, as well as for coach services. If a bus is constantly running at 73 kph, it can travel up to 420 kilometers per charge. With regard to short-distance routes, it allows buses to run three to four times in a row without charging. Thus, it ensures higher operating efficiency and profitability, if used during the morning and the evening rush hours. The 290-kWh battery can also be used for short-distance routes.

Hyundai ELEC CITY with Lithium Polymer Battery Hyundai ELEC CITY with Lithium Polymer Battery
Lithium Polymer Battery 290kWh

The 256 kWh high-capacity battery is designed for high-demand routes with heavy traffic congestion or hilly terrain, as well as for coach services. If travelling at a steady 73km/h, it has a range of up to 290 kilometers per charge. On short-distance routes, it can run three to four loops in a row without charging, and if applied to morning and evening rush hour routes, it ensures high operating efficiency and profitability. The 128-kWh battery can also be used for short-distance routes.

Safety

The Safety of Passengers is Our Top Priority

Front & Middle Door Ultrasonic Sensors
Bi-function Projector Headlamps & LED DRL
LED Rear Combination Lamps
Two Piece Glass & Basic Wiper

Cutting-edge Safety Specifications

Front/Middle Door Ultrasonic Sensors

Front and middle doors feature built-in ultrasonic sensors that are interlinked with the throttle to prevent safety accidents when passengers are entering and/or exiting the bus.

Bi-function Projector Headlamps & LED DRL (Daytime Running Lamp)

Powerful projector headlamps light up the road ahead to improve visibility.

LED Rear Combination Lamps (Stop Lamp, Taillight)

Two Piece Glass + Basic Wiper, Outside Mirror

Two-piece glass and basic wiper ensure the driver has an unobstructed, panoramic view. Right and left side mirrors mounted facilitate easy, quick shoulder checks.

Vehicle Dynamic Control (VDC)
Virtual Engine Sound & Reverse Parking Alarm

Cutting-edge Safety Specifications

Vehicle Dynamic Control (VDC)

Should tires lose their traction on ice, wet pavement, or in other unexpected driving scenarios, VDC is capable of selectively braking individual wheels to help the driver maintain full directional control and avoid an accident.

Virtual Engine Sound & Reverse Parking Alarm

Generates a virtual noise to alert the passenger about vehicle movement, and prevent mishaps. Parking alarm helps the driver when reversing.

Specifications

Unique, Cutting-Edge Specifications

specification-image specification-image

Key Specs

ELEC CITY
  • Seat capacity
    50 (27+1+22) / 51 (25+1+25)
Dimension
  • Wheel Base
    5,400 mm
  • Overall length
    10,995 mm
  • Overall width
    2,490 mm
  • Overall height
    3,400 mm

Seat capacity = passenger seats + driver seat + standing passengers.

Power Specs

Powertrain
  • Battery
    Lithium-polymer 290.4kWh (4 x 72.6kWh each)
  • Charging
    DC combo T2 (2EA)
  • Motor
    240kW (2 x 120kWh each)
Performance
  • All-electric range (AER)
    420km
Disclaimers

All designs, colors, features, and specifications shown and described in the contents of this website are provided for a general customer understanding and may differ from the actual product.
